Specification
Electrical Characterstics
Electrical
Characterstics
Parameters
Specification
Product Category?Description
Socket
Mounting style
Panel, Screw-type
Plug Size
Ø4.00
V/A Rating
10A, 250VAC
Insulation Resistance
100 M ohms Min
H.V.Break Down Test (For 1-Minute)
2 KVAC
Contact Resistance (Initial)
10 mohms max.
Operating/ Functional Characteristics
Operating/
Functional
Characteristics
Parameters
Specification
Permissible Temperature
-20°c to +85°c
Terminals
Solder-type
Material
Material
Parameters
Specification
Body
ABS
Colour
As per requirement
Contacts/Terminals
Brass, Tin plating
Reference Standard/ Approvals
Reference
Standard/
Approvals
Parameters
Specification
Reference Standard
JSS 52710
Compliance Marking
CE, RoHS ( On request )
Download PDF
Elcom BS-5 SERIES Data Sheet
51 KB
