Solar Connectors
With the aim to contribute to a greener economy and make sustainable energy available, Elcom international turned into a professional manufacturer of solar components in the year 2013. Thus becoming, India’s first manufacturer of solar components. Since its conception, Elcom International has established itself at the forefront of designing and manufacturing high-grade solar components which include PV cable connectors, branch connectors, module junction boxes, and PV wire harness solutions. They are widely used in all kinds of solar power applications. Elcom International has an ISO 9001:2015 certified manufacturing facility and these products have been certified by TUV as per IES standards.
Types Of Solar Connectors.
Features
Features Of Elcom Solar Connector
Our high-efficiency solar connectors, featuring an industry-leading ≤0.20 ohms contact resistance, maximize energy output, optimize power generation, and ensure consistent, reliable performance for your solar panels.
Our Elcom solar connector features a snap-in safety locking mechanism and an audible click. With over 40 years of expertise in electronic components manufacturing, we have created a connector that provides a secure and stable connection.
Designed to excel under extreme conditions, our 54A Connector delivers uncompromising performance, withstanding temperatures up to 125°C while effortlessly handling currents of 54A. Experience unrivaled reliability and seamless power transmission, making it the perfect solution for demanding solar applications in challenging high-temperature environments
Our high-efficiency solar connectors, featuring an industry-leading ≤0.20 ohms contact resistance, maximize energy output, optimize power generation, and ensure consistent, reliable performance for your solar panels.
ELCOM is the only Indian Manufacturer who has developed its solar connector with TUV certificate for 1500 VDC - as per the latest version of IEC 62852:2014 standard. We have received a TUV certificate for the PV cable connector ,panel mount, branch connector , which can operate at 1500 V DC.1
Benefits
Benefits Of Solar Connector
- Our solar connectors are suitable for use with both crystalline and thin-film panel manufacturers and system installers, providing versatility in various solar applications.
- The connectors have a high degree of protection with an IP68 rating, safeguarding against dust and water ingress.
- The connectors utilize copper with silver plating as the contact material, ensuring optimal conductivity.
- Secure Locking System: Our connectors feature a tool-based unlocking system, providing a secure and reliable connection.
- The connectors can withstand a wide operating temperature range from -40°C to +90°C, with an upper limiting temperature of 125°C, ensuring reliable performance in various environmental conditions.
- Our connectors are compatible with cable sizes of 2.5 sq.mm, 4 sq.mm, and 6 sq.mm, accommodating different solar installation requirements.
- The connectors require an insertion force of ≤ 50N and a withdrawal force of ≥ 100N, ensuring ease of use and a secure connection.
- The connectors utilize silicone material for effective sealing, providing protection against moisture and environmental elements.
