EC35
EC35
Specification
- Reference Standard
EN60939-3:2015 & EN60939-2:2005 standards
- Approval
CSA, CE, ROHS
Specification
Technical Specification
Technical
Specification
Parameters
Specification
Operating voltage
440VAC (P-P)
Current rating
3A - 40A
Frequency
50/60Hz
Voltage drop
1 Volt max
High potential test voltage
P -> E 1500VAC P -> P 2121VDC (applicable for general purpose filter)
Insulation resistance
≥ 300 MΩ @ 500VDC (P→E)
Operating temperature
40°c /-25°c +85°C
Safety Approval
Safety
Approval
Parameters
Specification
CE
Yes
CSA
Yes
ROHS
Yes
Features
Features of EC35 Three Phase Filter
Features
of
EC35
Three
Phase
Filter
All filters provide high attenuation performance.
General purpose filter with low leakage current for safety critical application.
CRCA metal can with nickel plating provides good aesthetic and corrosion protection.
All filters compliance to EN60939-3:2015 & EN60939-2:2005 standards.
Benefits
Benefits of EC35
Benefits
of
EC35
- High reliable and Single Stage.
- Chassis mountable filter in fabricated metal can.
- With surge suppressor filters also available.
- Various terminal options are available.
- Application: Electrical and electronic equipment, Test & measurement equipment, 3 Phase motor drive, Inverters and converters, Industrial automation application UPS, SMPS, Laser cutting tools, Packaging and drilling machine, Printing machine
Download PDF
ELcom EC35 Three Phase Filter
676 KB
