Specification
Electric Characteristics
Electric
Characteristics
Parameters
Specification
Voltage Rating (Max.)
600V
Maximum recommended connector current
20 AMPS
Operating/Functional Characteristics
Operating/Functional
Characteristics
Parameters
Specification
Durability (Mating Cycles Max.)
25
Circuits (Loaded)
1
Circuits (Max.)
1
Permissible Operating Temperature.
-25°C To 105°C
H V Test
3.4 kV
Insulation Resistance
100 MΩ
Flammability
UL 94 V-0.
Material
Material
Parameters
Specification
Plastic Body
Thermoplastic.
Contacts, Terminals
Copper Alloy, Tin Plating
Wire Size
12 AWG
Reference Standard/Approvals
Reference
Standard/Approvals
Parameters
Specification
Reference standards
UL 486A-486B
Compliance Marking
RoHS
Approvals
E-529684
Download PDF
Elcom IDC Wiretap Datasheet
967 KB
