KLS-5 SERIES
KLS-5
SERIES
Specification
- Reference Standard
IEC-61058-1 , UL-1054
- Compliance Marking
CE RoHS (On request, Please refer ordering code)
Specification
Electrical Characterstics
Electrical
Characterstics
Parameters
Specification
Switch type
Key operated, SPDT
V/A Rating
3A 250VAC,1VA 24VDC
Contact Resistance (Initial)
10m Ohms Max.
Insulation Resistance At 500 V DC
100M Ohms Min.
H.V.Break Down Test (For 1-Minute)
1KV AC
Mounting
Panel With Screw
Electrical life
10,000 Cycles Min.
Terminals Terminals
Solder-type
Operating/Functional Characteristics
Operating/Functional
Characteristics
Parameters
Specification
For Soldering
270oC, 5 Sec. Max.
With/Without Load
-25oC TO +85oC
Material
Material
Parameters
Specification
Body
Mazak
Terminals
Copper, Silver Plated
Contacts
Silver & Copper, Silver plated
Download PDF
KLS-5 Series Data Sheet
246 KB
