Specification
Electrical Characteristics
Electrical
Characteristics
Parameters
Specification
Type And Function
Rotary Switch
V/A Rating
4A, 250VAC / 125VAC
Contact Resistance(Initial)
20 m Ohms Max.
Insulation Resistance at 500 V DC
1000 M Ohms Min.
H.V.Break Down Test(For 1-Minute)
1 KV AC.
Operating/Functional Characteristics
Operating/Functional
Characteristics
Parameters
Specification
Mounting
Chassis With Screw
Terminals
Push-in type, 0.80 thick Min.
Electrical Life
10,000 Cycles/Pole
Permissible Temp.With/Without Load
-25°C TO +85°C
Permissible Temp For Soldering
270°C for 5 Sec. Max.
Material
Material
Parameters
Specification
Body
Nylon-GF.
Shaft
Nylon-GF;White
Current Carrying Parts
Brass/ Phosphor Bronze Nickel Platted
Reference Standard
Reference
Standard
Parameters
Specification
Reference Standard
IEC-1058-1(1996)
FEATURES
Tailored precision and compliance
Tailored
precision
and
compliance
Data Sheet
Elcom ERS-115 Data Sheet
248 KB
