EC06 DC Filter
EC06
DC
Filter
Specification
- Reference Standard
EN60939-3:2015 & EN60939-2:2005 standards.
- Conformance
CE, RoHS
Specification
Technical Specification
Technical
Specification
Parameters
Specification
Operating voltage
24 VDC
Current rating
1A to 6 Amp
Voltage drop
1 Volt max.
High potential test voltage
+,- to E 1500VAC
Insulation resistance
≥ 300 MΩ @ 500VDC (+,- to E)
Operating temperature
40°c /-25°c +85°c
Safety Approvals
Safety
Approvals
Parameters
Specification
CE marking
Yes
Features
Features of EC06 DC Filter
Features
of
EC06
DC
Filter
Two stage filters designed for noisy application requiring excellent filter performance.
CRCA metal can with nickel plating provides good aesthetic and corrosion protection.
Various terminal options are available
Easy and fast chassis mountable filter with compact size.
Download PDF
EC06 DC Filter Data Sheet
264 KB
