EE03
EE03
Specification
- Reference Standard
EN60939-3:2015 & EN60939- 2:2005 standards.
- Approval
CSA, ROHS
Specification
Technical Specification
Technical
Specification
Parameters
Specification
Operating voltage
120/250 VAC
Current rating
1A-10A
Frequency
50/60Hz
Voltage drop
1 Volt max.
High potential test voltage
P -> E 1500VAC P -> N 1414VDC (applicable for excluding surge suppressor filter)
Insulation resistance
≥ 300 MΩ @ 500VDC (PN→E)
Operating temperature
40°c /-25°c +85°c
Safety Approvals
Safety
Approvals
Parameters
Specification
CE marking
Yes
cCSAus
Yes
Features
Features of EE03 Filter
Features
of
EE03
Filter
All filters provide high attenuation performance.
Compact drill rail mounting design
Plastic housing with good aesthetic.
Input and output connection through wire
Filters available in medical version without capacitor to earth.
Single stage.
Benefits
Benefits Of EE03 Filter
Benefits
Of
EE03
Filter
- High reliable.
- With surge suppressor filters also available.
- Cost effective solution.
- Applications- Electrical and electronic equipment, Consumer product, Medical equipment, SMPS, Test & measurement equipment, Small to medium-sized machines and household equipment, Office automation equipment.
Download PDF
EE03 Filter Data Sheet
345 KB
