EB08
EB08
Specification
- Reference Standard
EN60939-3:2015 & EN60939-2:2005 standards
- Compliance Marking
CE, ROHS, CSA
Specification
Technical Specification
Technical
Specification
Parameters
Specification
Operating voltage
120/250 VAC
Current rating
1A-10A
Frequency
50/60Hz
Voltage drop
1 Volt max.
High potential test voltage
P -> E 1500VAC P -> N 1414VDC (applicable for excluding surge suppressor filter)
Insulation resistance
≥ 300 MΩ @ 500VDC (PN→E)
Operating temperature
40°c /-25°c +85°c
Safety Approvals
Safety
Approvals
Parameters
Specification
CE marking
Yes
cCSAus
Yes
Features
Features Of EB08 Filter
Features
Of
EB08
Filter
All filters provide high attenuation performance.
Filter available in panel mounting provision with deep drawn metal can.
CRCA metal can with nickel plating provides good aesthetic and corrosion protection
Provides double fuse protection.
Benefits
Benefits Of EB08 Filter
Benefits
Of
EB08
Filter
- Input connection through IEC 60320 C14 plug
- Have choice to select output connection type.
- Filters available in medical version without capacitor to earth. With surge suppressor filters also available.
- Applications - Consumer product, Defence application, Medical equipment, Industrial application, Electrical automation equipment, Test and measurement equipment
Download PDF
EB08-Series-1
399 KB
