EA04-PCB Mount
EA04-PCB
Mount
Specification
- Reference Standard
EN60939-3:2015 & EN60939- 2:2005 standards.
- Approval
CSA, CE, ROHS
Specification
Technical Specification
Technical
Specification
Parameters
Specification
Operating voltage
250/440 VAC
Current rating
1A - 10A
Frequency
50/60Hz
Voltage drop
1 Volt max.
High potential test voltage
P -> E 1500VAC P -> N 2121VDC (applicable excluding surge suppressor filter)
Insulation resistance
≥ 300 MΩ @ 500VDC (PN→E)
Operating temperature
40°c /-25°c +85°c
Safety Approval
Safety
Approval
Parameters
Specification
CE marking
Yes
Features
Features of EA04-PCB Mount Filter
Features
of
EA04-PCB
Mount
Filter
All filters provide high attenuation performance.
Compact PCB-mountable design.
Plastic housing with good aesthetic.
׀ Input and output connection through soldering pins.
Benefits
Benefits of EA04-PCB Mount
Benefits
of
EA04-PCB
Mount
- Filters available in medical version without capacitor to earth.
- ׀ With surge suppressor filters also available
- Cost effective solution.
- Single stage and High reliable.
- Application: Electrical and electronic equipment, SMPS , Test & measurement equipment, Small to medium-sized machines and household equipment, Office automation equipment
Download PDF
Elcom EA04-PCB Mount Data Sheet
413 KB
