EC38
EC38
Specification
- Reference Standard
EN60939-3:2015 & EN60939-2:2005 standards.
- Approval
CSA, ROHS, CE
Specification
Technical Specification
Technical
Specification
Parameters
Specification
Operating voltage
440VAC (P-P)
Current rating
50A - 80A
Frequency
50/60Hz
Voltage drop
1 Volt max.
High potential test voltage
P -> E 1500VAC
Insulation resistance
≥ 300 MΩ @ 500VDC (P→E)
Operating temperature
40°c /-25°c +85°C
Safety Approval
Safety
Approval
Parameters
Specification
CE
Yes
ROHS
Yes
Features
Features of EC38 Filter
Features
of
EC38
Filter
Filters available in double stage
All filters provide high attenuation performance.
Two stage filters designed for noisy application requiring excellent filter performance.
CRCA metal can with nickel plating provides good aesthetic and corrosion protection.
Benefits
Benefits of EC38
Benefits
of
EC38
- Easy and fast chassis mountable filter with compact size.
- Various terminal options are available.
- High reliable
- Application : Electrical and electronic equipment, Test & measurement equipment, 3 Phase motor drive, Inverters and converters, Industrial automation application UPS, SMPS, Laser cutting tools, Packaging and drilling machine, Printing machine
Download PDF
Elcom EC38 Data Sheet
361 KB
